Description
SONOREX TECHNIK RM 16.2 U-ST is an ultrasonic bath intended for industrial cleaning, service and maintenance work. Its welded oscillating tank of 2 mm stainless steel 1.4404 is built for long service life even under heavy duty. Modular construction allows flexible setups ranging from a single cleaning tank to a full cleaning line. An integrated overflow pocket is provided for connecting an oil separator so that removed oil films can be separated from the cleaning solution. The “-ST” designation indicates an interface with potential-free contacts for external control and monitoring—for example via PLC or robot-controller relay, control voltage, or a hand switch with signal lamp. Internal dimensions measure 325 × 275 × 200/210 mm. The bath has a tank volume of 20,0 l, ultrasonic peak power of 1200 W and nominal power of 300 W. Drainage is via a G ½ three-way ball valve complete with hose and hose nozzles in galvanically coated brass, mounted on the left side. Suitable baskets, lids and cleaning or disinfection concentrates are offered as accessories to support well-matched ultrasonic processes from manufacturer Bandelin.
This article is part of Ultrasonic baths & cleaners, in Ultrasonic baths & lab washers.
Key features
- Pack size: 1 pkg
- Tank volume: 20,0 l
- Ultrasonic peak power: 1200 W
- Nominal power: 300 W
- Internal dimensions: 325 x 275 x 200/210 mm
- EAN: 4250101110849
- Technical Information Sheet:
Recently viewed
You may also like
Questions about SONOREX TECHNIK FA 40 Filtration
What is this article?
SONOREX TECHNIK FA 40 Filtration is the article on this page. Luminix Health distributes Bandelin for laboratory use. It sits in Ultrasonic baths & cleaners, inside Ultrasonic baths & lab washers, in Lab instruments.
An ultrasonic cleaner drops parts into a bath where collapsing bubbles scrub joints and bores. Tank volume and ultrasonic power are the ratings. A basket keeps items off the tank floor, where the transducers are. The liquid is usually water plus a cleaning concentrate, not a strong solvent, unless the tank is rated for it.
An ultrasonic bath cleans by cavitation: the sound collapses tiny bubbles against the surface and lifts soil out of joints a brush cannot reach. The chemistry of the bath liquid still matters. A laboratory glassware washer is the machine that replaces hand washing when the load is large or the result has to be repeatable. Rinse water quality decides whether the glass comes out spotted. The ware being washed is listed under ISO laboratory glassware.
