Beschreibung
Ultra-pure water system , OmniaPure xs basic, incl. OmniaPure xs basic ultrapure water system, pretreatment and ultrapure water cartridge, sterile filter, 2 x PE hoses and R 3/4 water connection adapter. Contains LITHIUM-ION CELLS. Not subject to labelling according to ADR SV188., UN-Nr. 3091
The OmniaPure xsbasic device series supplies ASTM type I ultrapure water of the highest quality for analytical and life sciences applications, with a compact design optimised for resource conservation. The OptiFillbasic dispensing and monitoring unit, supplied as standard, enables precise filling of laboratory vessels. The recirculation function prevents biofilm formation.
- Usable with fully demineralised water
- OptiFillbasic ergonomic, flexible dispensing and monitoring unit with graphic display
- Two language settings available: DE, EN
- Ultrapure water withdrawal at the touch of a button
- Dispenser has a swivel range of up to 170°
- Display of all operating and performance parameters in real time
- Setting option for the conductivity display in MΩ x cm or μS/cm
- Compact design
- Space-saving mounting on a laboratory bench or optionally on a wall
- Password access
- Leak sensor
- Integrated pressure reducer
- Automatic voltage adjustment
- Ready to use, ready to connect, incl. filter cartridges
| Feed water requirements: water treated through ion exchange, reverse osmosis, deionisation or distillation | |
| Feed water temperature (°C) | +2-35 |
| Feed water pressure (bar) | 0.5-6 |
| Inlet conductivity (µS/cm) | <100 |
| TOC value (ppb) | <50 |
Note: the specified TOC values may vary depending on the quality of the feed water. The 0.2 µm sterile filter capsule is needed to meet the requirements for particle and bacteria content.
Typical applications: AAS, IC, ICP, buffer and media preparation.
Delivery incl. OmniaPure xsbasic pure water system, pretreatment cartridge, ultrapure water cartridge, sterile filter capsule (0.2 μm), PE tube Ø 8 mm (L 2.5 m), PE tube Ø 8 mm (L 2.5 m) incl. input protection filter and water connection adapter R 3/4″. Also includes UV lamp depending on the model.
Technical Information
| Type | OmniaPure xsbasic |
| Conductivity of high-purity water, type I | 0.055 µS/cm |
| Resistance of high-purity water, type I | 18.2 MΩ·cm |
| Withdrawal capacity of high-purity water, type I | ≤2 l/min |
| Bacteria content of high-purity water, type I | <0,01 KbE/ml |
| TOC value of high-purity water, type I | <10 ppb |
| Particle content of high-purity water, type I | <1/ml |
| Width | 240 mm |
| Depth | 435 mm |
| Height | 530 mm |
| Weight | 14 kg |
| Min. operating pressure | 0.5 bar |
| Max. operating pressure | 6 bar |
| Ambient temperature | 2-35 °C |
| Connection | R 3/4″ |
| Mains connection | 90-240 V, 50/60 Hz |
