Beschreibung
Laboklav 80-B ECO | Steam Sterilizer for the Sterilization of Solids and Liquids in Open Containers
• Vertical unit
• Usable chamber volume: 80 L
• Usable space (Ø x L in mm): 410 x 610
• Dimensions: 740 x 600 x 915 mm
• Operating overpressure: 2.8 / -1 bar
• Sterilization temperature: 98°C – 138°C
• Adjusted power consumption: 3 kW (230 V~, 50 Hz, 16 A)
• TÜV-certified motorized safety quick-lock with lip seal
• Thermal interlock according to TRB 402 and DIN 61010-2
• Flexible PT 100 reference sensor for liquid sterilization (time trigger based on medium temperature)
• Heating elements pressed against the outside of the chamber base, feed water inside the chamber
• Overheating protection in case of missing or insufficient feed water
• Gravity venting and pulsed venting for waste sterilization
• Integrated steam condensation, water-cooled, temperature-controlled, adjustable
• Validation port
• Safety valve, TÜV-certified component
• Internal memory chip for storing up to 10 cycles (readable afterwards)
• True 32-bit system with large multicolor touchscreen control panel and internal 16 GB memory
• Internal RS232 for printer connection
• External USB for printer, network, and computer connection
• Combined connection for drain lines
• Base support in the chamber
• Timer function
• Powder-coated housing
• Fully automatic microprocessor control with the following programs:
2 programs for solids
1 program for waste
2 programs for liquids
Each program can be configured by the operator (sterilization time, sterilization temperature).
Each program can be named individually (customizable per customer request).
Control / Documentation
• True 32-bit system with large multicolor touchscreen and internal 16 GB memory
• Additional membrane keypad with clear and easy-to-understand symbols
• All process data displayed
• Up to 10 programs accessible at the touch of a button and individually configurable
• Program access secured via code if desired
• Automatic documentation as PDF file directly in the control system’s internal memory
• All relevant process data and error messages included in a batch report
• Clearly structured graphical analysis
• Data transfer via USB: Automatic copying to USB stick
• USB port standard
• 16 GB memory chip for archiving at least 100,000 batch reports as standard
