Description
Roth Power Supply STANDARD, max. 300 V, max. 700 mA, max. 150 W, 4 mm sockets. Incl. power cable, w/o electrophoresis cables.
The Carl ROTH series - mature technology in modern designThree units for all applications in electrophoresis:MINI, STANDARD and BLOT.
- Compact and easy to operate
- Constant parameters
- Timer with alarm function
- Comply to all relevant safety standards
- 1 year warranty
For standard applications, all middle sized horizontal gels (routine gels) and for vertical mini gels. Suitable for cold-room operation.
Power Pro models (Roth STANDARD and Roth BLOT):
- Up to 30 individual protocols with 1-6 steps savable
- Pre-programmed options for special applications
- Connection with up to 5 units possible.
Technical Information
| Type | STANDARD (PowerPro3200) |
| Voltage range | 5-300 V |
| Current | 1-700 mA |
| Performance | 150 W |
| Volt-hours | 49,995 kVh |
| Timer display | 1-1999 min |
| Display type | 2,4″TFT |
| Resolution | 1 V1 mA |
| Unit of measurement | Constant V or mA with automatic crossoverDuring constant mode not adjusted parameters are automatically set to maximum |
| Program | Manually adjustable (Constant Mode) 30 programs, each with up to 6 steps editable (Program Mode) |
| Connection | Outlets: 5 Parallel socket pairs: 4 mm |
| Min. load resistance | 3 Ohm |
| Safety devices | Detection of "No load""Over load"and "Leakage"Protection against overheatingAutomatic recovery after power failure |
| Ambient temperature | 4-40 °C |
| Approval | CE, ETL |
| W x D x H | 21.5 x 33.5 x 10.4 cm |
| Weight | 2,1 kg |
| Mains connection | 100-240 V, 47-60 Hz, 200 W |
