Description
NEXOPART test sieve with stainless steel frame 315×75 mm is a particle-size analysis sieve fitted with stainless steel metal wire cloth. Frame diameter is 315 mm and height is 75 mm, giving a robust full-size format for laboratory and industrial sieving work. The woven metal wire cloth has a mesh aperture w of 90 mm and is produced from stainless steel in accordance with DIN ISO 3310-1. This combination of frame and cloth supports reproducible dry or wet sieving of coarse fractions where a large aperture is specified. The sieve from manufacturer NEXOPART uses stainless steel throughout the frame and wire cloth for mechanical stability and straightforward cleaning between runs. Net weight is 1,29 kg. Supplied as a single piece, it integrates into standard sieve stacks and shaker systems that accept 315 mm frames. Height, diameter and the defined 90 mm aperture together define a clear working geometry for classification tasks. The construction follows the dimensional and cloth requirements of DIN ISO 3310-1 for metal wire cloth test sieves used in quality control and materials testing.
Key features
- Pack size: 1 pc(s)
- Frame diameter: 315 mm
- Frame height: 75 mm
- Mesh aperture w: 90 mm
- Frame material: Stainless steel
- Cloth material: Stainless steel metal wire cloth
