Description
Pump head TH10A is a single-channel peristaltic pump head equipped with four rollers and designed for precise low-flow operation up to 41 ml/min. The head accommodates tubing with a wall thickness of 1 mm and an inner diameter from 1 to 3 mm, making it well suited to fine dosing, sampling and micro-volume transfer tasks in the laboratory. Compact construction keeps the fluid path short and controlled while the four-roller arrangement supports consistent occlusion across the stated tubing range. Offered as a single unit from manufacturer Landgraf HLL, the TH10A integrates readily with compatible peristaltic drives where accurate, gentle fluid handling is essential. Users select tubing materials according to chemical resistance and application needs, allowing the same head to serve aqueous buffers, solvents or other media within the mechanical limits of the tubing. Typical uses include analytical sample introduction, reagent addition and continuous low-rate delivery in research, quality-control and small-scale process setups that demand repeatable microlitre-to-millilitre performance.
This article is part of Shakers, rockers & rotators, in Stirring, shaking & mixing.
Key features
- Pack size: 1 pc
- Channels: 1
- Rollers: 4
- Max. flow rate: 41 ml/min
- Tubing wall thickness: 1 mm
- Tubing inner diameter: 1–3 mm
- Technical Information Sheet:
