Beschrijving
Density hydrometer type M50-110 is a precision glass instrument for determining liquid density in the working range 1,100–1,150 g/cm³ with a fine scale division of 0,001 g/cm³. Conforming to DIN 12791 and BS 718, it provides an accuracy of ±1 scale division and is specified for a reference temperature of 20 °C. The hydrometer is 270 mm long, supplied without an integrated thermometer, and designed for bottom (lower meniscus) reading, supporting clear visual evaluation during routine density checks. These attributes make the instrument suitable for analytical laboratories, production quality control and teaching environments where reproducible density measurement is required. The unit is calibratable, which helps laboratories maintain documented measurement capability within their quality systems. Offered as a single piece from manufacturer Amarell, the M50-110 density hydrometer combines a clearly graduated scale with standardised construction for dependable day-to-day use across its stated density interval.
This article is part of Hydrometers, in Density & viscosity measurement.
Key features
- Pack size: 1 pc
- Density: range: 1,100–1,150 g/cm³
- Type: M50-110
- Scale division: 0,001 g/cm³
- Accuracy: ±1 scale division
- Length: 270 mm
Recent bekeken
Misschien vind je dit ook leuk
Questions about Density hydrometer, type M50-110, DIN 12791/BS 718, 1,100-1,150:0,001g/cm³,
What is this article?
Density hydrometer, type M50-110, DIN 12791/BS 718, 1,100-1,150:0,001g/cm³, is the article on this page. Luminix Health distributes Amarell for laboratory use. It sits in Hydrometers, inside Dichtheids- & viscositeitsmeting, in Instrumenten.
A hydrometer floats in a liquid and the stem reading is the density or a related scale such as Brix. The liquid has to be at the temperature printed on the stem, or a correction is required. A chip on the stem changes the reading. One hydrometer does not cover every density.
Density is mass divided by volume. A hydrometer floats at a depth that depends on the density of the liquid. A pycnometer is a vessel of known volume that is weighed full. Viscosity is the resistance to flow. A capillary viscometer times how long a volume takes to fall through a tube. Both measurements need a stated temperature, because liquids change density and viscosity as they warm. The units trace to the BIPM and to NIST.
