Beschreibung
Gas pressure regulator, two stage, brass, 0.5-10 bar, nitrogen
Material: brass, chrome-plated.
For all pure and ultra-pure gas mixtures, apart from acetylene and corrosive gases. For applications requiring a constant initial pressure.
Technical Information
| Gas type | Nitrogen |
| Upstream pressure, max. | 200 bar |
| Back pressure | 0,5-10 bar |
| Readability | 0.5 bar |
| Bottle connection | W 24.32 x 1/14″ right |
| Inlet connection | bottle connection according to DIN 477 |
| Outlet connection | clamping ring screw connection for 6 mm pipe |
| Total leakage rate | 3 x 10-7 mbar l/s |
| Operating temperature | -20 to +50 °C |
| L x W x H | 180 x 98 x 135 mm |
| Weight | 1,6 kg |
