Description
PILZ® -Protect-Line- LP2 housing heating mantle is a laboratory heating mantle for 1,000 ml round-bottom flasks (Ø 131 mm), rated 300 W at 230 VAC with a maximum permissible operating temperature of 450 °C. The hand-crocheted glass-silk heating element is built to protection class I and sits in a powder-coated, chemically resistant metal housing. A two-part design with a liquid-tight upper section and permanently affixed volume warning markings supports safe bench use. Two heating zones are selectable via a dedicated zone switch with integrated “heating” status lamp, alongside a main on/off switch; all controls are safety switches that help prevent unintended operation. Equipment includes a detachable connector (cable length 0,50 m) and a personnel-protection plug with residual-current function plus Schuko type E/F mains cable (1,00 m). Net weight is 2,5 kg (gross 2,65 kg); housing dimensions are 205 mm width and 205 mm height. This Protect-Line standard unit from manufacturer Winkler suits controlled heating of round flasks in chemical and analytical workflows where robust enclosure protection and clear zone control are required.
This article is part of Heating mantles, in Heating, drying & cooling.
Key features
- Pack size: 1 pc
- Product type: LP2 -Protect-Line-
- Flask volume: 1,000 ml
- Rated power: 300 W
- Max. operating temperature: 450 °C
- Heating zones: 2
- Technical Information Sheet:
