Description
Muffle furnace L5/13/B510 is built for demanding thermal work up to a maximum temperature of 1300 °C. Freely radiating heating elements on support tubes provide rapid heat-up and durable performance, with energy input from two sides of the chamber. Multi-layer insulation with robust lightweight refractory bricks enables the higher working temperature and makes the furnace an attractive option versus familiar L(T)./12 units when elevated application temperatures are needed. A dual-shell ventilated housing of textured stainless steel sheets reduces surface temperature and adds stability. This variant features a flap door usable as a work platform and a thermocouple feed-through for flexible temperature monitoring. Adjustable air inlet in the door and rear-wall exhaust outlet support controlled atmosphere exchange. The B510 touch controller manages five programs with four segments each, while solid-state relays ensure quiet operation. NTLog Basic allows process-data logging to a USB flash drive. Pack size is 1 pc; the furnace is offered by manufacturer Nabertherm for laboratory applications within the stated operating limits.
This article is part of Muffle & tube furnaces, in Heating, drying & cooling.
Key features
- Pack size: 1 pc
- Model: L5/13/B510
- Maximum temperature: 1300 °C
- Door type: Flap door
- Controller: B510 (5 programs, 4 segments each)
- Special equipment: Thermocouple feed-through
Recently viewed
You may also like
Browse related categories
Category
Sub-category
Catalogue
Brand
Questions about Muffle Furnace L5/13/B510 Tmax1300 with flap door and thermocouple hole in the f
What is this article?
Muffle Furnace L5/13/B510 Tmax1300 with flap door and thermocouple hole in the f is the article on this page. Luminix Health distributes Nabertherm for laboratory use. It sits in Muffle & tube furnaces, inside Heating, drying & cooling, in Lab instruments.
A muffle furnace surrounds a sample with heat for ashing or ignition, often to 1100 °C. A tube furnace heats a sample in a controlled atmosphere inside a tube. The maximum temperature and the chamber size are the specification. A drying oven is not a furnace.
Temperature equipment either holds a set point or drives a sample toward one. An oven dries. A furnace reaches the temperatures of ashing and melting. A bath surrounds a vessel with water or oil. A circulator moves that fluid. An incubator holds the mild warmth of a culture. An autoclave uses steam under pressure to sterilise. The number that matters is the temperature the article actually reaches, not the number painted on the dial. Temperature is part of the international system kept by the BIPM and compared by EURAMET.
