Description
The muffle furnace L5/13/B510 is a laboratory furnace for a maximum working temperature of 1300 °C. Heating elements on support tubes radiate freely into the chamber, giving particularly short heating times and a long service life. Multi-layer insulation with robust lightweight refractory bricks supports this elevated temperature range and makes the model a useful alternative when higher application temperatures are needed than with familiar L(T)./12 units.
This article is part of Muffle & tube furnaces, in Heating, drying & cooling.
Heat is applied from two sides. The dual-shell ventilated housing is made of textured stainless steel sheets for low outer surface temperature and high stability. The flap door can be used as a work platform; an adjustable air inlet in the door and an exhaust air outlet in the rear wall support controlled air exchange. This version includes a thermocouple feed-through. The touch controller B510 provides five programs with four segments each, and solid-state relays ensure low-noise operation. NTLog Basic records process data via USB flash drive. Supplied as one unit from manufacturer Nabertherm for defined laboratory use within the operating instructions.
Key features
- Pack size: 1 pc(s)
- Model: L5/13/B510
- Maximum temperature: 1300 °C
- Controller: B510 (5 programs, 4 segments each)
- Door type: Flap door
- Special feature: Thermocouple feed-through
Recently viewed
You may also like
Browse related categories
Category
Sub-category
Catalogue
Brand
Questions about Muffle Furnace L5/13/B510 Tmax1300 with flap door and thermocouple port in the r
What is this article?
Muffle Furnace L5/13/B510 Tmax1300 with flap door and thermocouple port in the r is the article on this page. Luminix Health distributes Nabertherm for laboratory use. It sits in Muffle & tube furnaces, inside Heating, drying & cooling, in Lab instruments.
A muffle furnace surrounds a sample with heat for ashing or ignition, often to 1100 °C. A tube furnace heats a sample in a controlled atmosphere inside a tube. The maximum temperature and the chamber size are the specification. A drying oven is not a furnace.
Temperature equipment either holds a set point or drives a sample toward one. An oven dries. A furnace reaches the temperatures of ashing and melting. A bath surrounds a vessel with water or oil. A circulator moves that fluid. An incubator holds the mild warmth of a culture. An autoclave uses steam under pressure to sterilise. The number that matters is the temperature the article actually reaches, not the number painted on the dial. Temperature is part of the international system kept by the BIPM and compared by EURAMET.
