Description
Muffle furnace L5/13/C550 is a laboratory muffle furnace for a maximum working temperature of 1300 °C. Heating elements on support tubes radiate freely into the chamber, giving particularly short heating times and a long service life. Robust multi-layer insulation with lightweight refractory bricks supports this elevated temperature range and makes the model a practical alternative to familiar L(T)./12 units when higher application temperatures are needed. Heat is applied from two sides inside a dual-shell ventilated housing of textured stainless steel sheets, which keeps outer surfaces cooler while preserving high stability. The flap door can be used as a work platform; an adjustable air inlet is integrated in the door and an exhaust air outlet is located in the rear wall. The touch-operated C550 controller handles process programs, and solid-state relays provide low-noise operation. NTLog Basic enables process data recording with a USB flash drive. This Nabertherm configuration includes a temperature selector limiter and is offered as one complete unit for defined laboratory use within the operating instructions.
This article is part of Muffle & tube furnaces, in Heating, drying & cooling.
Key features
- Pack size: 1 pc
- Model: L5/13/C550
- Maximum temperature: 1300 °C
- Door type: Flap door
- Controller: C550
- Heating: Two-sided, elements on support tubes
