Description
Muffle furnace L5/13/C550 Tmax1300 with flap door, protective gas connection and temperature is a laboratory muffle furnace rated for a maximum working temperature of 1300 °C. Heating elements mounted on support tubes radiate freely into the chamber, enabling particularly short heating times and extended element life. Robust multi-layer insulation with lightweight refractory bricks allows this higher working temperature and positions the furnace as an alternative to standard L(T)./12 models when greater heat is needed. Dual-shell ventilated construction from textured stainless steel sheets reduces external surface temperature while maintaining high stability. The flap door can be used as a work platform; the door also carries an adjustable air inlet, with an exhaust air outlet in the rear wall and a protective gas connection. Heating is provided from two sides. The B510 touch controller manages five programs of four segments each, and solid-state relays support low-noise operation. NTLog Basic records process data via USB flash drive. The unit is offered as 1 pc from manufacturer Nabertherm for defined laboratory applications within the operating instructions.
This article is part of Muffle & tube furnaces, in Heating, drying & cooling.
Key features
- Pack size: 1 pc
- Maximum temperature: 1300 °C
- Door type: Flap door
- Protective gas connection: Integrated
- Controller: B510 touch (5 programs, 4 segments)
- Heating: Two sides, elements on support tubes
