Description
Muffle furnace L9/13/B510 is a laboratory muffle furnace designed for a maximum working temperature of 1300 °C. Heating elements mounted on support tubes radiate freely into the furnace chamber, enabling short heating times and extended element life. Thanks to multi-layer insulation with robust lightweight refractory bricks, the furnace reaches this higher temperature range and serves as a useful alternative to the well-known L(T)./12 models when greater application temperatures are needed. Heating is arranged from two sides. The dual-shell ventilated housing uses textured stainless steel sheets to limit outer surface temperature and maintain high stability. This variant features a flap door that can act as a work platform together with a thermocouple feed-through. An adjustable air inlet is fitted in the furnace door, and an exhaust air outlet is located in the rear wall. The B510 controller with touch operation provides 5 programs with 4 segments each; solid-state relays support low-noise running, and NTLog Basic allows process data recording with a USB flash drive. These units from manufacturer Nabertherm are intended for defined laboratory applications within the operating instructions. Pack size is 1 pc.
This article is part of Muffle & tube furnaces, in Heating, drying & cooling.
Key features
- Pack size: 1 pc
- Model: L9/13/B510
- Maximum temperature: 1300 °C
- Door type: Flap door
- Equipment: Thermocouple feed-through
- Controller: B510 (5 programs, 4 segments each)
