Description
Muffle furnace L9/13/C550 is a high-temperature laboratory muffle furnace rated for a maximum working temperature of 1300 °C. Freely radiating heating elements on support tubes deliver short heating times and extended element life inside the chamber. Robust lightweight refractory brick insulation in a multi-layer build enables this higher working range and offers a clear alternative to standard L(T)./12 models when greater application temperatures are required.
This article is part of Muffle & tube furnaces, in Heating, drying & cooling.
Energy is introduced from two sides. A dual-shell ventilated housing of textured stainless steel sheets keeps surface temperatures low and provides high mechanical stability. This variant combines a flap door, usable as a work platform, with a thermocouple feed-through. The door carries an adjustable air inlet; an exhaust air outlet is placed in the rear wall of the furnace. Control is via the B510 touch controller with 5 programs of 4 segments each, while solid state relays support low-noise operation. NTLog Basic allows process data recording with a USB flash drive. Intended use remains within the operating instructions for this unit from manufacturer Nabertherm, offered as one complete piece.
Key features
- Pack size: 1 pc
- Model: L9/13/C550
- Maximum temperature: 1300 °C
- Door type: Flap door
- Feature: Thermocouple feed-through
- Controller: B510 touch operation (5 programs, 4 segments)
