Description
Quantum Pro trinocular microscope is a high-quality laboratory instrument with infinity-corrected optics and a 30° Siedentopf-type head that swivels, offering 47–75 mm interpupillary adjustment and full 360° rotation. It is fitted with WF10X/20 mm eyepieces and a reversed quadruple revolving nosepiece on bearings for smooth, precise objective changes. The achromatic infinity objectives cover 4X, 10X, 40X and 100X (oil), each with anti-fungal treatment for reliable long-term use. A mechanical double-layer stage of 140 x 140 mm provides 75 x 50 mm X-Y travel and a 0,1 mm Vernier scale for accurate specimen positioning. Coaxial focusing includes tension control, a safety stop and micrometric accuracy of 0,002 mm. The centreable Abbe condenser (N.A. 1,25) carries a position scale, while intensity-adjustable high-efficiency S-LED illumination supports clear brightfield viewing. Supplied with case, blue, green and grey filters, fuse, hand rest and 100–240 V adapter from manufacturer Labbox, the instrument includes a 2-year warranty and suits teaching, routine diagnostics and research laboratories needing stable trinocular imaging.
This article is part of Microscope objectives, eyepieces & optics, in Microscopy & histology.
Key features
- Pack size: 1 pc
- Head: Siedentopf trinocular, 30°, 360° rotation
- Eyepieces: WF10X/20 mm
- Objectives: 4X, 10X, 40X, 100X (oil) achromatic infinity
- Stage: 140 x 140 mm, 75 x 50 mm X-Y travel
- EAN: 8434868115811
Recently viewed
You may also like
Browse related categories
Category
Sub-category
Microscope objectives, eyepieces & optics
Catalogue
Brand
Questions about Quantum Pro microscope, trinocular head
What is this article?
Quantum Pro microscope, trinocular head is the article on this page. Luminix Health distributes Labbox for laboratory use. It sits in Microscope objectives, eyepieces & optics, inside Microscopy & histology, in Lab instruments.
An objective makes the resolution. Magnification and numerical aperture are the two numbers, and the tube length or the infinity correction has to match the microscope. An eyepiece mostly enlarges the image the objective already resolved. A mismatched objective does not become sharper by zooming.
A light microscope forms an image with glass lenses and transmitted or reflected light. A stereo microscope is the lower-magnification instrument for dissecting and for looking at a surface. Fluorescence needs a light source and filters matched to the dye. Histology is the preparation that makes a tissue readable: fixation, a cassette, a section, a stain. The objective's magnification and numerical aperture decide the resolution. The slide and the cover glass decide whether the section sits in the focal plane. Stains and dyes as substances are identified on PubChem. Papers on the methods are on PubMed.
Which category should I open next?
The category is Microscopy & histology. The sub-category is Microscope objectives, eyepieces & optics. The catalogue is Lab instruments.
Shelves beside this one are Microscope slides & cover glasses, Histology cassettes & moulds, Counting chambers & haemocytometers, Stereo microscopes, Light & fluorescence microscopes, Histology reagents & consumables, Microscopy accessories, Cold light sources & lighting and Digital & USB microscopes.
What should I check before I order?
When this page shows a safety data sheet, use that manufacturer file. Hazard text does not belong in the sales description. For a pack size, a grade or a certificate that is not on the page, send a quote request or contact the team.
