Description
• usable as floor-standing or tabletop unit
• usable chamber volume 160 l
• usable space (ØxL in mm) 500 x 760
• operating overpressure 2.8 / -1 bar
• sterilization temperature 98°C - 138°C
• TÜV-approved motor-driven safety lock
• separate, integrated steam generator (10 kW) with the latest dry heating element technology
• integrated reservoir for demineralized water (automatic and manual filling), level monitoring
• thermal lock in accordance with TRB 402 and DIN 61010-2
• flexible PT 100 reference sensor for liquid sterilization (time trigger via medium temperature)
• gravity and pressure-pulse air removal (waste sterilization)
• integrated condensate cooling system, water-cooled, temperature-controlled, adjustable
• validation port
• safety valve, TÜV-approved component
• internal memory chip for storing up to 150 cycles (readable afterward)
• common drain outlet
• bottom support in the interior
• timer function
• powder-coated housing
• fully automatic microprocessor control with the following programs: open programs - 3 solid material programs - 2 waste sterilization programs in disposal bags - 1 liquid waste program - 4 liquid programs; password-protected programs - 10 freely programmable as solid, waste, or liquid programs
Each program can be configured by the operator (sterilization time, temperature). Each program can be named individually (according to customer requirements).
Control / Recording
• true 32-bit system with large multicolor touch panel and internal 16 GB memory
• additional membrane keypad with clear and intuitive symbols
• all process data displayed
• up to 20 programs available at the push of a button and customizable
• code-protected program access possible
• automatic documentation as PDF file stored directly in the internal memory
• all relevant process data and error messages included in a batch report
• clear graphical evaluation
• data transfer via USB: automatic copying to a USB stick
• USB port standard
• 16 GB memory chip for archiving at least 100,000 batch reports (standard)
Key features
- Technical Information Sheet:
