Description
Drying and heating oven ED260UL-240V is a natural-convection drying and heating chamber for routine drying and sterilisation applications up to 300 °C. The unit provides a nominal volume of 255 l and a temperature range from ambient temperature +5 °C to +300 °C, with high temperature accuracy ensured by APT.line™ technology. Natural convection enables efficient thermal processes and supports rapid, homogeneous drying. Equipment includes a controller with LCD display, electromechanical control of the exhaust air flap, two chrome-plated shelves, an integrated temperature selector limiter Class 2 (DIN 12880) with optical alarm, ergonomic handle design, USB connection for data recording and an Ethernet interface. Offered as 1 pc with United States plug (Type A/B), this oven from manufacturer Binder is suited to laboratory drying and heating workflows. Net weight is 93 kg and gross weight is 95 kg.
This article is part of Drying ovens & climate chambers, in Heating, drying & cooling.
Key features
- Pack size: 1 pc
- Nominal volume: 255 l
- Temperature range: ambient +5 °C to +300 °C
- Convection: natural convection
- Technology: APT.line™
- Interface: Ethernet
- Manufacturer: Binder
- UNSPSC: 41104502
- Interior dimensions: 610 × 550 × 760 mm (W × D × H)
- Exterior dimensions: 810 × 760 × 940 mm (W × D × H)
- Weight, empty: 85 kg
- Voltage: 240 V, 60 Hz
- Nominal power: 2.45 kW
- Temperature uniformity at 150 °C: ±1.8 K
- Temperature fluctuation at 150 °C: ±0.8 K
- Heating-up time to 150 °C: 50 min
- Recovery time after a 30 s door opening at 150 °C: 20 min
- Air change rate at 100 °C: 3 x/h
- Shelves, standard / maximum: 2/8
- Load per rack: 40 kg
- Permitted load: 270 kg
- Energy consumption at 100 °C: 195 Wh/h
- Energy consumption at 150 °C: 355 Wh/h
- Wall clearance, side: 100 mm
- Wall clearance, back: 160 mm
- Technical Information Sheet:
- Data Sheet:
