Description
Stereo Microscope L90 with trinocular head is a Greenough-system stereo microscope designed for clear three-dimensional observation in laboratory and inspection work. The head tilts at 45° and rotates through 360°, with ±5 diopter adjustment on both sides, selectable beam-split ratios of 50/50, 20/80 and 0/100, and an interpupillary distance adjustable from 54 mm to 76 mm. Wide-field WF10X/20 mm eyepieces pair with a continuous zoom objective of 0,7X–4,5X to deliver a standard magnification range of 7X–45X, extendable with optional accessories to 2,1X–270X. Adjustable LED illumination supports both incident and transmitted light. The base includes a transparent stage plate and specimen holders for stable sample positioning. Offered as a complete unit from manufacturer Labbox, the instrument has a net weight of 7,600 kg and is supplied as 1 pc. A two-year warranty accompanies the microscope, supporting routine stereo imaging tasks that require flexible viewing angles, dual illumination and a practical zoom range.
This article is part of Microscope objectives, eyepieces & optics, in Microscopy & histology.
Key features
- Pack size: 1 pc
- Optical system: Greenough
- Head: Trinocular, 45° inclined, 360° rotatable
- Zoom objective: 0,7X–4,5X continuous
- Magnification: 7X–45X (expandable to 2,1X–270X)
- EAN: 8434868111943
- GTIN: 08434868111943
- Technical Information Sheet:
