Description
Drying and heating oven ED 56-230V is a compact laboratory oven for routine drying and sterilisation work up to 300 °C. The temperature range runs from +5 °C above ambient temperature to +300 °C, with high temperature accuracy ensured by APT.line™ technology. Natural convection drives efficient thermal processes and supports fast, uniform drying throughout the 57 l chamber. An LCD controller and electromechanical exhaust-flap control simplify daily use, while two chrome-plated shelves and a stackable housing aid flexible installation. An integrated class 2 temperature limiter to DIN 12880 with optical alarm contributes to safe operation. Ergonomic handle design and a USB interface for data recording complete the feature set. Up to 30 % more energy-efficient than typical market devices, the ED series from manufacturer Binder is well suited to reliable drying and heat-treatment tasks. Programmable operation with program memory and a time switch supports reproducible protocols. Supplied as 1 pc with Euro plug (type C) for 230 V mains connection.
This article is part of Drying ovens & climate chambers, in Heating, drying & cooling.
Key features
- Pack size: 1 pc
- Nominal volume: 57 l
- Temperature range: +5 °C above ambient to +300 °C
- Convection type: Natural convection
- Max. operating temperature: 300 °C
- Interface: USB
- Manufacturer: Binder
- UNSPSC: 41104502
- Interior dimensions: 360 × 380 × 420 mm (W × D × H)
- Exterior dimensions: 560 × 565 × 625 mm (W × D × H)
- Weight, empty: 39 kg
- Voltage: 230 V, 50/60 Hz
- Nominal power: 1.05 kW
- Temperature uniformity at 150 °C: ±2.3 K
- Temperature fluctuation at 150 °C: ±0.4 K
- Heating-up time to 150 °C: 50 min
- Recovery time after a 30 s door opening at 150 °C: 19 min
- Air change rate at 100 °C: 8 x/h
- Shelves, standard / maximum: 2/4
- Load per rack: 30 kg
- Permitted load: 70 kg
- Energy consumption at 100 °C: 105 Wh/h
- Energy consumption at 150 °C: 180 Wh/h
- Wall clearance, side: 100 mm
- Wall clearance, back: 160 mm
- Technical Information Sheet:
- Data Sheet:
