Description
LAUDA Versafreeze VF 15040 is a laboratory ultra-low temperature upright freezer for long-term storage and quality assurance of organic substances and other materials. The working temperature range is −40 to 0 °C, with temperature constancy of ±2 K and temperature homogeneity of 3 K at −40 °C. A single inner compartment protected by an insulated door helps limit cold loss. The stainless-steel usable chamber offers 129 L (480 × 480 × 560 mm); external dimensions are 904 × 776 × 865 mm and net weight is 128 kg. The compact design is under-counter capable for integration into a laboratory bench line or freestanding use. Vacuum insulation maximises internal volume relative to footprint. A tightly laid cooling coil supports rapid freezing and stable temperatures; cool-down from 20 °C to −40 °C is 5 h and warm-up from −40 °C to 0 °C is 12 h. Energy consumption is 5 kWh/d at −40 °C. This model from manufacturer Lauda includes a 4,3″ touchscreen for setpoint and safety values, password-protected user management, electronic alarm with potential-free contact for building systems, battery-buffered display and alarms, integrated data logger, Ethernet (IIoT-ready) and RS 485 interfaces, two standard 13 mm ports for control sensors, magnetic door seals, and an energy-efficient, maintenance-free hermetic refrigeration circuit with natural refrigerant R-1270. Mains supply is 230 V; 50 Hz with angled Schuko cable (CEE7/7).
This article is part of Circulators, chillers & thermostats, in Heating, drying & cooling.
Key features
- Pack size: 1 piece
- Working temperature range: −40 … 0 °C
- Useful volume: 129 L
- Temperature constancy: ±2 K
- Power supply: 230 V; 50 Hz
- Manufacturer: Lauda
- Net weight: 128 kg
- UNSPSC: 41103020
- Ambient temperature: 15...28 °C
- Exterior dimensions: 904 × 776 × 865 mm
- Weight: 128 kg
- Voltage: 230 V; 50 Hz
- Technical Information Sheet:
Recently viewed
You may also like
Questions about LAUDA Versafreeze VF 15040 Upright Freezer 230 V; 50 Hz
What is this article?
LAUDA Versafreeze VF 15040 Upright Freezer 230 V; 50 Hz is the article on this page. Luminix Health distributes Lauda for laboratory use. It sits in Circulators, chillers & thermostats, inside Heating, drying & cooling, in Lab instruments.
A circulator or thermostat holds a bath liquid at a set temperature and pumps it through a jacket. A chiller is the same idea aimed below ambient. The temperature range, the cooling power and the pump flow are the three numbers. The fluid has to match the range.
Temperature equipment either holds a set point or drives a sample toward one. An oven dries. A furnace reaches the temperatures of ashing and melting. A bath surrounds a vessel with water or oil. A circulator moves that fluid. An incubator holds the mild warmth of a culture. An autoclave uses steam under pressure to sterilise. The number that matters is the temperature the article actually reaches, not the number painted on the dial. Temperature is part of the international system kept by the BIPM and compared by EURAMET.
Which category should I open next?
The category is Heating, drying & cooling. The sub-category is Circulators, chillers & thermostats. The catalogue is Lab instruments.
Shelves beside this one are Muffle & tube furnaces, Heating mantles, Drying ovens & climate chambers, Water & oil baths, Hot plates & heating blocks, Incubators, Heating & cooling (other), Temperature control accessories, Laboratory refrigerators & freezers, Autoclaves & sterilisers, Bunsen & gas burners and Heating tapes, cables & plates.
What should I check before I order?
When this page shows a safety data sheet, use that manufacturer file. Hazard text does not belong in the sales description. For a pack size, a grade or a certificate that is not on the page, send a quote request or contact the team.
