Description
Biological Microscope Vision+ with trinocular head is a versatile light microscope for routine laboratory observation of stained and unstained specimens. The trinocular head is inclined at 30°, fully 360° rotatable, and offers an adjustable interpupillary distance of 55 mm to 75 mm for comfortable dual viewing and camera work. A quadruple nosepiece carries achromatic objectives 4X, 10X, 40X and 100X (spring-loaded, oil immersion), paired with a wide-field WF10X/18 mm eyepiece. The double-layer mechanical stage measures 132 × 142 mm and provides a 75 × 40 mm travel range for precise specimen positioning. Coaxial coarse and fine focusing delivers 0,004 mm precision. Illumination is supplied by an adjustable LED system through an Abbe condenser N.A. 1,25 with iris diaphragm. The instrument from manufacturer Labbox is supplied complete with dust cover, fuse, filter and 100–240 V adapter and carries a two-year warranty. Net weight is 9,600 kg. Ideal for teaching laboratories, clinical screening and general biological research where reliable bright-field imaging is required.
This article is part of Microscope objectives, eyepieces & optics, in Microscopy & histology.
Key features
- Pack size: 1 pc
- Head: Trinocular, 30° inclination, 360° rotatable
- Eyepiece: WF10X/18 mm wide-field
- Objectives: Achromatic 4X, 10X, 40X, 100X (oil)
- Stage: Double-layer mechanical 132 × 142 mm
- EAN: 8434868111899
- GTIN: 08434868111899
- Technical Information Sheet:
Recently viewed
You may also like
Browse related categories
Category
Sub-category
Microscope objectives, eyepieces & optics
Catalogue
Brand
Questions about Vision+ Biological Microscope, trinocular head
What is this article?
Vision+ Biological Microscope, trinocular head is the article on this page. Luminix Health distributes Labbox for laboratory use. It sits in Microscope objectives, eyepieces & optics, inside Microscopy & histology, in Lab instruments.
An objective makes the resolution. Magnification and numerical aperture are the two numbers, and the tube length or the infinity correction has to match the microscope. An eyepiece mostly enlarges the image the objective already resolved. A mismatched objective does not become sharper by zooming.
A light microscope forms an image with glass lenses and transmitted or reflected light. A stereo microscope is the lower-magnification instrument for dissecting and for looking at a surface. Fluorescence needs a light source and filters matched to the dye. Histology is the preparation that makes a tissue readable: fixation, a cassette, a section, a stain. The objective's magnification and numerical aperture decide the resolution. The slide and the cover glass decide whether the section sits in the focal plane. Stains and dyes as substances are identified on PubChem. Papers on the methods are on PubMed.
